HIGH TEMPERATURE CRYSTAL OSCILLATORS SERVING EXTREME TEMPERATURE AND DOWN HOLE APPLICATIONS
Q-Tech has long been the leader for high reliability, high temperature crystal oscillators for harsh environments, such as downhole drilling, oil and gas exploration and perforation, logging, high temperature avionics, jet engine sensors, geothermal energy and other industrial applications.
Our high temperature products have all been rigorously qualified and are tested to the highest standards and high temperature materials are utilized with proven process methodologies in order to provide high temperature crystal oscillators for extreme environment applications. We continue to push the state of the art including smaller size packages, lower power, current requirements, and Real Time Clock (RTC) modules.
Standard packages, including ultra miniature SMD, can be supplied to withstand temperatures up to +200°C in harsh high shock and vibration environments for packages as small as 2.5x3.2mm and supply voltage as low as 1.8V (CMOS). Additionally, Q-Tech can provide oscillators up to +225°C in certain packages; please consult the factory.
The difference between our products and our competitors’ is in our outstanding reliability, performance and quality. In addition to standard Screening and QCI per MIL-PRF-55310, custom Source Control Drawings (SCDs) allow Q-Tech to offer a broad range of device screening and qualification options that are tailored to customer requirements.
- General High Temperature Product Offerings
- QTCH High Temperature Oscillators (5 x 7, 3.2 x 5, 2.5 x 3.2 mm ultra miniature surface mount)
- 5x7mm High Temperature including 4-point mount
- 5x7mm 32.768kHz Oscillator +200°C for Real Time Clock
- 5x7mm 32.768kHz Oscillator, extreme low current for RTC
- Real Time Clock SPI QT1123L, extreme low current
- Real Time Clock I2C QT2024L, extreme low current
Top of Table
Similar Pages
Articles
| Data Sheet | Image | Package | Dimensions (mm) | Market | Device Type | Logic Type | Supply Voltage | Package Type | Stability | Phase Noise Floor | View Outline |
|---|---|---|---|---|---|---|---|---|---|---|---|
| QTCH High Temperature Oscillators |  | QTCH230 | 2.50 x 3.20 x 1.15 | High Temp | XO | CMOS | 1.8 to 3.3Vdc | Surface Mount (Miniature SMD) 2.5 x 3.2mm 4 Pad | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QTCH High Temperature Oscillators (32K768) | | QTCH230 (32K768) | 2.50 x 3.20 x 1.15 | High Temp | XO | CMOS | 2.5 to 3.3Vdc | Surface Mount (Miniature SMD) 2.5 x 3.2mm 4 Pad | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QTCH High Temperature Oscillators |  | QTCH350 | 3.20 x 5.00 x 1.20 | High Temp | XO | CMOS | 1.8 to 3.3Vdc | Surface Mount (Miniature SMD) 3.2x5mm 4 pads | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QTCH High Temperature Oscillators (32K768) | | QTCH350 (32K768) | 3.20 x 5.00 x 1.20 | High Temp | XO | CMOS | 2.5 to 3.3Vdc | Surface Mount (Miniature SMD) 3.2 x 5mm 4 Pads | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QTCH High Temperature Oscillators |  | QTCH570 | 5.00 x 7.00 x 1.40 | High Temp | XO | CMOS | 1.8 to 3.3Vdc | Surface Mount (Miniature SMD) 5 x 7mm 4 Pads | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QTCH High Temperature Oscillators (32K768) | | QTCH570 (32K768) | 5.00 x 7.00 x 1.40 | High Temp | XO | CMOS | 2.5 to 3.3Vdc | Surface Mount (Miniature SMD) 5 x 7mm 4 Pads | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QT1123L RTC |  | QT1123L, QS1123L, QG1123L | 22.35 x 12.83 x 5.08 | High Temp | XO - RTC | CMOS | -5.2 to -4.5Vdc & 1.8 to 15Vdc | Dual In-line (DIP-14) 14 Pin | ±40ppm to ±250ppm | Contact Q-Tech | View |
| QT2024 |  | QT2024 | 12.8 x 12.8 x 5.08 | High Temp | XO - RTC | CMOS | 3.3Vdc | Through Hole | ±40ppm to ±250ppm | Contact Q-Tech | View |
| QT38x RTC |  | QT380, QT381, QT382, QT383, QT384, QT385, QT386, QT387, QS380, QS381, QS382, QS383, QS384, QS385, QS386, QS387 | 5.0 x 7.0 x 2.54 | High Temp | XO - RTC | CMOS | 2.5 to 3.3Vdc | Surface Mount (Miniature SMD) 5 x 7mm Thru Hole 6 Pin | ±150ppm to ±250ppm | Contact Q-Tech | View |
| QTCH500 High Temperature DIP |  | QTCH500, QTCH510, QTCH550 | 12.83 x 12.83 x 5.08 | High Temp | XO | ACMOS, CMOS, ECL/PECL, HCMOS, LVHCMOS, TTL, Z | 1.8 to 5Vdc | Dual In-line (DIP-8) 4 Pin | ±100ppm to ±250ppm | Contact Q-Tech | View |
| QT58x and QT59x | | QT581, QT582, QT583, QT584, QT588, QT589, QT590, QT592, QS581, QS582, QS583, QS584, QS588, QS589, QS590, QS592 | 5.00 x 7.00 x 2.00 | High Temp | XO - RTC | CMOS | 2.5 to 3.3Vdc | Surface Mount (Miniature SMD) 5 x 7mm Thru Hole 6 Pin | ±40ppm to ±250ppm | Contact Q-Tech | View |
| High Temperature 5x7 |  | QT81, QS81 | 5.00 x 7.00 x 2.00 | High Temp | 5x7 w/ 4pt Mount | CMOS, LVHCMOS, TTL | 1.8 to 5Vdc | Surface Mount (Miniature SMD) 5 x 7mm Thru Hole 4 Pin | ±175ppm to ±450ppm | Contact Q-Tech | View |
| High Temperature 5x7 | | QT86 | 5.00 x 7.00 x 2.00 | High Temp | 5x7 w/ 4pt Mount | CMOS, LVHCMOS, TTL | 1.8 to 5Vdc | Surface Mount (Miniature SMD) 5 x 7mm Thru Hole 6 Pin | ±175ppm to ±450ppm | Contact Q-Tech | View |
